30kW lahkawng maga de shinggyin tawn da ai Inverter
30kW Bidirectional Storage Inverter gaw, modular battery n-gun shinggyin ai ladat ni a n-gun galai shai ai core hku nna magam gun nna, battery, AC n-gun, grid lapran n-gun galai shai ai lam hpe hkang zing ya ai.
Sut masa n-gun hpe shinggyin la na matu, backup n-gun hpe garan gachyan na matu, garan gachyan ai n-gun hpe shinggyin la na matu galaw da ai ndai compact n-gun hpe shinggyin la lu na inverter gaw system integrators ni hpe BESS hkrang shapraw na matu n-gun n-gun rawng ai npawt nhpang jaw ya ai. Shi gaw bungli galaw ra ai lam amyu myu hte masing masa ni hpe madi shadaw ya ai, dai sha n-ga, n-gun hte n-gun atsam ra kadawn ai lam ni rawt jat wa ai hte maren, htawm hpang de jat wa na matu shara tawn da ya ai.
Madung lam ni
BESS hpe n-gun rawng ai hku hpawng de nna jat wa na matu madung lam ni.
Lam lahkawng hku n-gun galai shai ai lam
Battery system hte AC maga lapran hta hkang lu ai charge hte discharge hpe galaw ya lu ai, hpaga yumga n-gun hpe shinggyin la lu na matu, backup n-gun hpe backup galaw lu na matu, microgrid galaw lu na matu n-gun hpe madi shadaw ya lu ai.
Battery kaba hte htuk manu ai lam
150–750V battery n-gun gaw, n-gun rawng ai hkrang masa hpe madi shadaw ya ai, lithium, lead{2}}acid, sodium-ion, hte flywheel shingbyi shara ni hte htuk manu ai lam gaw, bungli masing hpe gram lajang na matu lata la mai ai lam ni hpe grau dam lada hkra galaw ya ai.
Kaji ai Rack-Gaw da ai hpawng de ai lam
19-inch rack hte htuk manu ai hkrang gaw BESS cabinet kata kaw jung na matu asan sha galaw ya ai, system hpe hpaw shalawm ai ni hpe shara ra ai lam hpe shayawm ya lu ai hte jak rung ni hpe gram lajang ya lu ai.
Scale galaw mai ai Parallel jat wa ai lam
AC hte DC maga lahkawng yan hta parallel galaw ai gaw modular atsam rawt jat galu kaba wa na hpe madi shadaw ya ai. Off-grid power kaba ra ai lam ni a matu unit 10 du hkra parallel hku nna bungli galaw mai ai.
Hkrang n bung ai jan hte backup lata la mai ai lam ni
Laksan PV charger langai gaw DC-coupled solar-plus-hkap la ai ladat ni hpe madi shadaw ya nna, ra ai aten hta shi hkum shi backup galaw ya lu ai.
Kaja ai hte matut mahkai ai bungli galaw ai lam
97.3% du hkra peak efficiency hte CAN, RS485, Ethernet, hte WiFi matut mahkai lam ni hpe galaw lu ai majaw, lahkawng maga na inverter gaw kaja ai hku bungli galaw lu ai hte n-gun rawng ai system matut mahkai lam hpe madi shadaw ya lu ai.
Laksan masat masa
| Batteri maga | |
| Charge galaw ai hte jahkrat kau ai voltage shadawn shadang | 150V-750V (350V-750V @hkum tsup ai) |
| Rated n-gun | 30kW |
| Grau htum ai atsam | 33kW |
| Grau htum ai charge hte discharge galaw ai | 90A |
| Battery hpe pat kau ai ladat | Relay |
| Over Voltage hpe makawp maga ai lam | Software hpe makawp maga ai lam |
| Ya aten hta grau nna makawp maga ai lam | Software makawp maga ai lam & DC Fuse |
| DC Bus Maga | |
| Rated n-gun | 45kW |
| Shang bang ai n-gun n-gun | 700V-830V |
| Ya aten hta grau law ai shang wa ai | 32.5A*2 |
| AC pru wa ai | |
| Rated prut n-gun | Grid hpe gyit da ai/hkap la ai: 30kW |
| Grau htum ai dan dawng ai atsam | Grid hpe gyit da ai/hkap la ai: 33kVA |
| Grau htum ai atsam | Grid hpe gyit da ai/hkap la ai: 33kW |
| Rated Grid wan n-gun | 3P3W+PE, 480 (±15%) n-gun n rawng ai 3P3W+PE, 480 (±5% gram lajang mai ai) Vac |
| Rated chyahkring hkring | (±2.5) Hz Grid n lawm ai: 60 (±5 hpe gram lajang mai ai) Hz |
| N-gun atsam |
Grid-hkap da ai/hkap la ai-grid: Lahta na: 0.8~1 ningbaw ningla (sh) hpang hkrat ai Teng sha nga yang:0.1~1 ningbaw ningla (sh) hpang hkrat ai |
| THDi | <3% |
| Grai law hkra lit la lu ai atsam |
110%~120%, minit 10 120%~130%, minit 1 130%~150%, 200ms >150%, 100ms |
| -grid hte maren sha re | |
| Shinggan na galai shai jak | Droop hkang ai lam bung ai/Matut mahkai ai lam bung ai: Rai sai |
| Parallel law dik htum | Droop hpe hkang ai parallel/Matut mahkai ai lam hte maren: 10 |
| Parallel line ni a galu kaba ai lam yawng |
Droop hpe hkang ai parallel: Shadawn sharam n nga ai Matut mahkai lam bung ai: 7m |
| Madung masat da ai lam | |
| Kaja dik ai akyu rawng ai lam | 97.3% |
| CEC shadawn ai akyu rawng ai lam | 95.5% |
| Matut mahkai hka hkin gau | RS485/Ethernet/WIFI |
| Shadawn shadang (WHD) |
440×173×550mm 440x173x596mm (lagaw ni lawm ai) |
| Katsi ai | Nbung hpe atik anang katsi shangun ai |
| Shen yu ai | 33kg |
| Topology | -n garan tawn da ai |
| Magam bungli tsaw ai shara | 3000m (>3000m shayawm ai) |
| Bungli galaw ai grup yin awu asin byin ai madang | hta n law ai (sh) maren sha re. |
| Katsi ai hte katsi ai | -30℃~60℃ (>45℃shayawm ai) & 0-95% |
| Mahku | 75dB hta n law ai (sh) maren sha re. |
| IP masat masa | IP20 |
| Grid-hkap da ai madang | IEEE1547;UL1741SA;tara 21 |
| Hkamja lam masat masa | UL1741; UL9540A |
| EMC madang | FCC |
Modular BESS a matu 30kW Battery n-gun galai shai ai ladat
Battery n-gun hpe mahkawng da ai bungli masing ni hta, a .Lahkawng maga de na mahkawng da ai inverterngu nna mung tsun mai ai.Lahkawng maga na battery galai shai ai jak, n-gun mahkawng da ai PCS, BESS galai shai ai jak, shing nraiN-gun galai shai ai ladat (PCS). Shi a lit gaw, battery system hte AC wan n-gun network lapran na AC/DC n-gun galai shai ai lam hpe hkang na matu re.
Ndai 30kW PCS hpe 150–750V battery bungli galaw ai window, 30kW rated charge/discharge n-gun, 480Vac masum{5}}phase AC n-gun, grid{6}}hkap da ai hte n-gun n-rawng ai grid bungli galaw ai masat masa ni, modular parallel ni hku nna lachyum shaleng da ai. Dai wan n-gun lamu ga jarit ni gaw, BESS langai ngai a battery voltage, AC bus, cabinet layout, control architecture ni hta inverter hpe hkan sa lu na kun ngu ai hpe dawdan ya ai majaw, n-gun kaba ai jai lang ai masat kumla ni hta grau nna, arung arai lata ai lam hta grau akyu rawng nga ai.
Lahkawng maga de n-gun lwi ai
Inverter gaw charge galaw ai hte discharge galaw ai maga lahkawng yan hta bungli galaw ai.
Battery maga de gaw masat da ai voltage/current envelope kata na DC power hpe hkang ai;
AC maga de gaw 3P3W+PE, 480Vac system hte matut mahkai nga ai.
Charge galaw ai lam
AC power hpe DC de galai nna battery charge galaw ai. Charge n-gun hte n-gun gaw battery system a shadawn sharam hte inverter a 30kW / 90A bungli galaw ai envelope kata kaw sha nga ra ai.
Shapraw ai lam
Stored DC n-gun hpe 3-phase AC de galai shai kau ai. Inverter gaw shi a pru ai, n-gun, n-gun, n-gun-factor, hte n-gun grai law ai shadawn sharam kata kaw active-power command hpe galaw ai.
Hkang ai lamu ga jarit
PCS gaw galai shai ai lam hpe galaw ai; grup yin na battery, BMS, EMS (sh) site controller gaw bungli galaw ai shadawn sharam, ahkang, aten masat masa, hte project-madang ladat ni hpe jaw ya ai.
30kW System hpe hpaw shalawm ai
30kW Modular n-gun galai shai ai block
30kW rating gaw, shinggyin tawn da ai n-gun atsam hpe n re ai sha, kalang ta galai shai ai atsam hpe tsun dan ai. Battery kWh gaw kade daram n-gun nga ai hpe dawdan ya nna, PCS kW gaw dai n-gun hpe madi shadaw ai voltage hte current shadawn sharam kata hta kade daram lawan ai hku charge (sh) discharge galaw lu ai hpe dawdan ya ai.
01
150–750V Battery-Maga mi hte maren shatai ai lam
Charge/discharge galaw ai window gaw 150–750V lapran rai nna, full-load galaw ai lam hpe 350–750V kaw nna masat da ai. Htap htuk ai hpe shingdaw ai-n-gun kaba ai battery ladatdai majaw SOC hta grau nna tengman ai pack voltage hpe jep yu ra ai, BMS a ya na shadawn sharam ni hpe jep yu ra ai, yaw shada ai bungli galaw lu ai atsam-nominal battery voltage hpe sha n-ga.
02
480Vac Masum-Phase AC hpawng de ai lam
AC maga de gaw 3P3W+PE, 480Vac hte 60Hz ngu masat da ai. Grid-hkap la ai n-gun hpe 480Vac ±15% ngu masat da ai; off-grid n-gun hpe 480Vac ±5% hku nna gram lajang mai ai. Ndai gaw unit hpe a .480V masum-hpang battery galai shai ai jakdai AC platform grup yin hta galaw da ai system ni a matu.
03
N-gun atsam hte bai htang ai lam-N-gun atsam n-gun atsam
AC interface a matu, THDi hpe 3% npu hte ningbaw/hpang hkrat ai atsam-factor atsam hpe masat da ai. Ndai parameters ni gaw 30kW PCS hpe facility AC bus langai mi hta bang da ai shaloi ahkyak ai rai nna, dai shara a wan hte matut mahkai lam ra kadawn ai lam ni kata kaw bungli galaw ra ai.
04
Parallel PCS htingnu gawgap ai lam
30kW PCS gawgap ai htinggaw hpe Parallel Unit 10 du hkra shadawn shadang galaw u.
Dai system gaw, langai ngai hpe lang nna, unit shi du hkra parallel bungli galaw ai hpe madi shadaw ya ai.
droop hpe hkang ai (sh) matut mahkai lam-madung tawn ai parallel hpe hkang ai. Capacity rating n bung ai ni a matu converter n bung ai masat masa ni hpe lang ra na n re.
Droop hkang ai lam hte matut mahkai ai lam bung ai
| Parameter | Droop hpe hkang ai parallel | Matut mahkai lam Parallel |
| Shinggan na galai shai ai jak | Mai sa | Mai sa |
| Grau htum ai Parallel Unit ni | 10 | 10 |
| Parallel line ni yawng a galu kaba ai lam | Shadawn sharam n nga ai | 7m |
19-Inch Rack hta jung da ai PCS hpe BESS Cabinet hpe hpaw shalawm na matu
Mechanical format gaw ndai model a grau nna hkrak ai deployment arawn alai langai mi rai nga ai. 440mm-dam ai chassis, rack-htap htuk ai hkrang, atik anang-nbung hpe katsi shangun ai hte IP20 masat masa ni gaw, grau kaba ai hkang zing da ai wan n-gun shingdu (sh) BESS cabinet kata de bang na matu yaw shada ai PCS hpe madun ai.
- Chassis shadawn shadang:440 × 173 × 550 mm
- Lata ni hte:440 × 173 × 596 mm
- Shen yu ai:33kg
- Katsi ai:Atik anang nbung
- IP masat masa:IP20
- Topology:-n garan tawn da ai
Htingnu -madang hkrang shapraw ai lam:rack hte htuk manu ai lam gaw, shingbyi shara engineering hpe n galai shai ya ai. Nbung lwi ai lam, daw jau ai lam hpe htingnut kau ai lam, grup yin nbung katsi ai lam, awu asin byin ai madang, cable lam hkawm ai lam, makawp maga ai lam, cabinet IP rating ni gaw BESS hkrang shapraw ai lam hkum tsup ai hta naw lawm nga ai.
PV charger hte hpaji rawng ai htawt sit ai ladat hpe hpaw shalawm ai
Anhte gaw shapoi ai arung arai amyu myu hpe jaw ga ai
DC-Hkrumzup ai PV + Battery Hkrang Shapraw ai lam
Optional PV charger gaw, DC maga de na PV hpe shapraw ya lu ai. Ndai hkrang masa hta, battery PCS gaw battery-to-AC de lahkawng maga de galai shai ai lam hpe matut nna hparan ya nna, PV charger gaw PV-maga de DC galai shai ai lam hpe hparan ya ai. Ndai gaw grau hkrak ai hku tsun dan na matu re .DC-hkap la ai battery shingbyi sharanpawt nhpang arung arai hpe hybrid inverter ngu nna masat da ai hta grau nna.
Grid/Backup htawt sit ai htingnu gawgap ai lam
Laksan lata la mai ai smart transfer switch gaw backup-madung ai system hkrang shapraw ai lam ni hta ra ai galai shai ai layer hpe jaw ya ai, PCS gaw AC/DC n-gun galai shai ai lam hpe lit la nga ai. Switching function hpe PCS function kaw na garan ginhka ai gaw, hkum tsup ai wan n-gun htingnu hta gara kaw htawt sit ai, garan ginhka ai, makawp maga ai hte n-gun galai shai ai lam ni byin ai hpe asan sha chye lu ai.
30kW lahkawng maga de shinggyin tawn da ai Inverter FAQ
San: Battery n-gun shinggyin ai ladat hta 30kW rating ngu ai lachyum gaw hpa rai ta?
A: 30kW rating gaw inverter a rating n-gun-galai shai lu ai atsam re. PCS gaw aten langai hta kade daram atsam hpe galaw lu ai lam hpe tsun dan ai; dai gaw battery a n-gun atsam hpe kWh hku nna n tsun dan ai. Dai majaw battery n-gun hte PCS n-gun hpe garan nna raitim, matut mahkai ai BESS parameters hku nna size galaw ra ai.
San: Ndai PCS gaw 150–750V battery range ting hta 30kW tup hte bungli galaw lu na kun?
A: Lajang da ai masat da ai lam hta 150–750V charge/discharge voltage range hpe ka da nna, 350–750V hpe full load hta laksan tsun da ai. Dai majaw, jai lang mai ai SOC range hta jan ai battery pack voltage hpe ra ai bungli galaw ai atsam hte shingdaw nna jep yu ra ai.
San: Ndai gaw 480V masum-phase battery galai ai jak rai kun?
A: Rai sai. AC masat masa hta 3P3W+PE, 480Vac hpe grid-hkap da ai hte n-hkap la ai-grid bungli galaw ai lam lahkawng yan a matu ka da ai. Grid-hkap la ai n-gun hkam sharang ai lam hpe ±15% ngu masat da ai; off-grid n-gun hpe ±5% hku nna gram lajang mai ai ngu masat da ai.
San: 30kW PCS unit kade hpe parallel hku galaw lu na kun?
A: Off-grid gram lajang ai lam ni hta droop hkang ai lam (sh) matut mahkai lam-madung tawn ai parallel bungli galaw ai lam hpe jai lang nna lajang da ai parallel unit 10 du hkra jai lang mai ai. Project-laksan masa shadawn sharam ni hpe n sawn shi yang, 30 kW module shi gaw 300 kW ngu ai module rating hpe madi madun ai.
San: Ndai product hta droop-hkang ai hte matut mahkai ai lam-parallel configuration ni gaw hpa shai ai kun?
A: Droop-hkang ai parallel hpe yawng line-galu ai shadawn sharam n nga ai sha madun da ai, matut mahkai parallel hpe gaw 7m kaw ka da ai. Hpang jahtum na bungli masing gaw lata la ai hkang zing ai hte wiring htingnu gawgap ai ladat hpe hkan sa ra ai.
San: Inverter hte gara battery chemistry ni hpe hpaw shalawm mai ai kun?
A: Dai arung arai hte seng ai shiga hta, lithium, lead{0}}acid, sodium-ion, hte nbungli n-gun hpe shinggyin tawn da ai lam ni hpe ka da ai. Battery chemistry hpe sha n-ga, battery a n-gun, current, BMS a shadawn sharam, makawp maga ai logic, matut mahkai lam hte bungli galaw ai matsun ni hpe shingdaw nna, htuk manu ai lam hpe naw jep joi ra na re.
San: BMS hte EMS hpe hpaw shalawm na matu gara matut mahkai lam ni hpe lang mai ai kun?
A: Ndai jahpan hta lawm ai matut mahkai lam ni gaw CAN, RS485, Ethernet hte WiFi ni rai nga ai. Integration engineering gaw lata la ai battery hpareng ai ladat hte n-gun hpareng ai ladat a matu hkrak tup protocol hpe hkan sa ai lam hte ra ai data point ni hpe madi shadaw ra ai.
San: 30kW unit gaw hybrid jan n-gun rawng ai jak rai kun?
A: Base product hpe lahkawng maga hku shinggyin tawn ai Inverter / battery PCS ngu nna tsun da ai. Dai arung arai hte seng ai shiga hta DC-hkap la ai jan-plus-hpaji masa ni a matu lata la mai ai PV charger hpe ka da ai. Dai gaw, dedicated PV MPPT input hpe standard PCS kata de bang da ai ngu sawn la ai hte shai ai.
San: BESS cabinet kata de PCS hpe bang ai shaloi hpa hpe myit yu ra ai kun?
A: Ndai arai gaw 19-inch rack hte htuk manu ai, 33kg n-gun rawng ai, nbung hpe atik anang katsi shangun ai hte IP20 ngu masat da ai. Cabinet hpe hpawng de ai shaloi, jak rung madi shadaw ai lam, nbung lwi ai lam, daw jau ai lam hpe lu la na matu, cable lam hkawm ai lam, grup yin nbung katsi ai lam, awu asin byin ai madang, makawp maga ai lam hte hpawng de ai lam hta ra ai shingdu shingwang masat masa ni hpe myit yu ra ai.
30kW PCS ra ai lam hpe bawngban u
Na a battery voltage, ra ai PCS power, grid hkrang shapraw ai lam, project ra ai lam ni hpe garan gachyan ya u. Ndai lam ni hpe lang nna 30kW Bidirectional Storage Inverter gaw na a BESS hkrang hte bung ai kun ngu ai hpe jep yu mai ai.
