261kWh 160KW Trailer hta jung da ai n-gun atsam hpe mahkawng da ai ladat
261kWh 160kW Trailer hta jung da ai Mobile N-gun Hkringmang Dap gaw, grid n-gun n law ai (sh) n ngang grin ai masa ni hta, n-gun n law ai, ra sharawng ai hku n-gun jaw na matu galaw da ai re. DC lawan ai hku charge galaw lu ai atsam hte n-gun kaba ai -hkum hkrang n-gun hpe kayau kaya hpaw nna, aten kadun shara ni, lawan ladan madi shadaw ai lam, mobile charge galaw ai application ni a matu kam mai ai n-gun hpe jaw ya lu ai. Liquid cooling, high efficiency, hte hpaji rawng ai n-gun hpe hkang lu ai atsam ni gaw, grai sawng ai makau grup yin ni hta ngang grin ai hku bungli galaw lu shangun ai, trailer-mounted design gaw lawan ai hku n-gun dat lu nna, loi loi hte htawt sit lu shangun ai, npawt nhpang gawgap ai lam hta kam hpa ai lam hte bungli galaw ai lam hta pat shingdang ai lam ni hpe shayawm ya lu ai.
Core Parameters a lachyum hte ahkyak ai lam
261 kWh (kilowatt-hkying hkum) - N-gun atsam:
■Ndai gaw battery hta shinggyin la lu ai wan n-gun grau law ai hpe madun ai: kilowatt-hkying hkum (kWh) 261 daram.
■Ndai atsam madang hpe mobile n-gun shinggyin ai arung arai ni hta lapran tsang kaw nna kaba ai hku sawn la ai, lapran tsang kaw nna kaba ai-scale aten kadun n-gun jaw ai lam (sh) peak shaving scenario ni hta law malawng lang ai.
160 kW (kilowatt) - Masat da ai prut n-gun:
■Ndai gaw, dai jak gaw AC (sh) DC n-gun kaba dik htum 160 kilowatts (kW) hpe matut manoi shapraw lu ai hpe madun ai.
■Ndai gaw, n-gun dat dat ai shaloi, system gaw kade daram n-gun dat lu ai hpe dawdan ya ai (ga shadawn, generator galai ai, jak rung ni hpe n-gun jaw ai, etc.).
Trailer-Gaw da ai / Hkrun lam:
■Ndai system hpe towable chassis/frame ntsa hta hpaw da ai majaw, lam hkawm ai hku nna shara shagu lapran lawan ai hku garan gachyan lu ai.
■Fixed energy storage cabinet ni hte shingdaw yu yang, mobile system a kaba dik ai akyu gaw, hpa gap bungli mung n galaw ra ai sha jai lang mai ai lam rai nga ai.
Na a n-gun ra kadawn ai lam ni a matu kaja dik htum galaw da ai
Mobile hpe galai shai mai ai hku jai lang ai
Trailer-mounted structure gaw lawan ai hku jung lu nna, loi ai hku htawt sit lu ai majaw, ndai system hpe aten kadun shara ni, lamang ni, gawgap ai shara ni, hte lawan ladan n-gun madi shadaw ai lam ni hta ngang grin ai npawt nhpang n nga ai sha, grai kaja ai.
Hpaji -N-gun atsam hpe mahkawng da ai shara
261 kWh rated n-gun hte n-gun kaba -htuk manu ai n-gun galai shai ai lam hte, ndai system gaw off-grid (sh) n-gun kya ai-grid makau grup yin ni hta matut manoi charge galaw ai hte wan n-gun hpe madi shadaw na matu ngang grin ai, aten galu-n-gun hpe jaw ya lu ai.
Lawan ai hte hkrak ai hku charge galaw ai
160 kW du hkra n-gun rawng ai Dual DC charge output ni gaw EV hpe lawan ai hku charge galaw ya lu ai, service hpe grau kaja hkra galaw ya lu ai hte mobile (sh) aten kadun charge galaw ai masa hta la nga ai aten hpe shayawm ya lu ai.
Grid Shanglawt hte Backup Power
Built-in energy storage gaw grid n-gun n-nga ai aten hta kam mai ai n-gun jaw ya ai, n-htum n-wai charge galaw ai lam ni hpe galaw ya ai hte ahkyak ai application ni a matu bungli galaw ai lam hta kam hpa mai ai lam hpe grau kaja hkra galaw ya ai.
Peak Shaving hte manu jahpu hpe grau kaja hkra galaw ai
Off-peak hours aten hta n-gun hpe shinggyin tawn da nna, ra kadawn ai aten hta discharge galaw ai hku nna, ndai system gaw grid load hpe rap ra hkra galaw ya nna, wan n-gun manu hpe bungli galaw ai aten tup hta shayawm ya lu ai.
Hkamja lam hte ngang grin ai bungli galaw ai lam
Liquid cooling, high-accuracy DC metering, hte wan hkru ai hpe makawp maga ai lam ni hpe hpawng de da ai gaw, nbung katsi ai shara law law hta shim lum ai, hkrak hkra galaw lu hkra galaw ya ai, hkrat sum na hkrit tsang hpa hte gram lajang ai lam hpe shayawm ya lu ai.
Laksan masat masa
|
Sawn hpajang magam
|
Parameter masat kumla ni
|
Tsun shaga ai lam
|
|
Kasi
|
160KW/261kWh hkawm sa ai n-gun mahkawng da ai ladat
|
|
|
Madung cabinet shadawn shadang ni
|
2928mm×1500mm×1628m
|
Galu * sung * tsaw
|
|
Rated N-gun
|
261kWh
|
|
|
Rated n-gun
|
160kW
|
|
|
Ac shang ai wan n-gun
|
380V
|
Masum-daw manga-wire masa
|
|
Ac shang ai n-gun
|
50Hz
|
|
|
Shapraw wan n-gun
|
DC150-1000V
|
|
|
Ya aten na pru wa ai
|
250A hta n law ai (sh) maren sha re,Sinat lahkawng
|
|
|
N-gun atsam
|
0.99 hta grau kaba ai (sh) maren sha re.
|
50%P0 jan ai pru wa ai masa ni.
|
|
N-gun marai
|
95% hta grau kaba ai (sh) maren sha re
|
Peak akyu rawng ai lam
|
|
Shadawn shadang ladat
|
Dc wan n-gun meter shadawn ai
|
Tengman ai lam 0.5.
|
|
Katsi ai ladat
|
Ntsin katsi ai
|
|
|
Hka katsi ai jak a masat da ai lam ni
|
5kW/Cabinet langai hpra gaw shanglawt ai
|
Unit 1
|
|
Wan makawp maga masing
|
Nbung-melt n-gun rawng ai wan sat jak
|
|
|
Tsaw ai shara
|
2000m hta n law ai (sh) maren sha rai yang Frequency hpe shayawm ra ai lam n nga ai
|
1000m jan tsaw ai shara ni a matu, tengman ai
altitude manu hpe masat da ra ai. Shagu shagu a matu
100m jat wa yang, bungli galaw nga ai
nbung katsi ai hpe 1 hte shayawm ra ai.
|
|
Nbung n-gun
|
80kPa-110kPa
|
|
|
Bungli galaw ai nbung laru
|
-30 degri -50 degri
|
100 hta jan ai shayawm ai atsam hta bungli galaw u.
50 hta bungli jahkring kau na.
|
|
Relative hka n-gun
|
0-95％
|
Hka lim ai lam n nga ai
|
|
Charge galaw ai shara
|
GB/T20234.3-2023 DC charge galaw ai matut mahkai lam
|
|
|
Matut mahkai lam
|
4G, RS485, CAN, Ethernet (ra sharawng ai)
|
|
|
Matut mahkai ladat
|
Modbus -RTU/Modbus -TCP/IEC104
|
|
|
Hpang jahtum ladat
|
Card hpe swipe (sh) code hpe scan galaw nna galaw hpang u .
|
Madung bungli galaw ai lam hpe madun ai
| Madun ai | Lachyum / Tsun dan ai lam |
|---|---|
| N-gun atsam | 261 kWh |
| Wan jak mawdaw ni a matu ngang grin ai galu kaba lam hpe jat ya lu ai | |
| Grau htum ai prut n-gun | 160 kW |
| Lawan ai hku charge galaw lu ai atsam hpe galaw ya ai | |
| Battery a prat | Typically >6000–8000 shingjawng ai lam, nbung laru/charge-hprawng pru ai sung ai lam a majaw hkra machyi ai |
| Bungli galaw ai Voltage n-gun | Kalang lang 150-1000 V DC zawn re ai ni hpe lang ai. |
| Katsi ai Ladat | Hkring hkra bungli galaw lu na matu n-gun kaba a matu ntsin katsi shangun ai |
| Makawp maga ai masat masa | IP54, IP55 etc. shinggan makawp maga ai masat masa |
| Shawng nnan mahtai jaw ai aten | Boot aten<5 ms, enables rapid response to load fluctuations |
System a madung daw ni
Lithium-ion battery n-gun mahkawng da ai ladat (BESS)
- Kaja wa nga yang, lithium iron phosphate (LFP) battery ni hpe lang ai gaw, shim lum ai lam grai law ai hte, n-gun galu ai majaw re.
- Battery cell a hkrang masa (1P260S zawn re ai ni) gaw voltage hte current a arawn alai ni hpe dawdan ya ai.
Battery hpe hparan ai ladat (BMS)
- Battery pack a n-gun, n-gun n-gun, SOC (State of Charge) ni hpe yu reng nna hkang zing na lit nga ai.
- Hkamja lam hpe grau kaja hkra galaw ya nna, battery a prat hpe galu shangun ai.
Inverter / N-gun galai shai ai ladat (PCS)
- Battery kaw na DC power hpe AC power de galai shai ya ai (load (sh) grid de pru wa ai).
- Grau law ai pru wa ai atsam hpe dawdan ya ai; ndai ga shadawn hta, 160 kW daram re.
Katsi ai hpe hkang ai ladat (ntsin katsi ai (sh) nbung katsi ai)
- Battery a n-gun hpe hkang lu ai; liquid cooling gaw grau hkrak ai hku hkang lu na matu hte grai sawng ai makau grup yin ni hpe hkan sa lu na matu ahkang jaw ai.
- Large-scale system ni gaw shim lum lam hte asak galu lam hpe grau kaja hkra galaw na matu hka hpe katsi shangun ai ladat ni hpe lang chye ai.
Wan hkru makawp maga ai hte shim lum ai ladat ni .
- Hkamja lam hpe ladat amyu myu hku nna galaw ai, dai hta wan hkut hpe mu lu ai jak, nbung katsi ai hpe chye lu ai jak, aerosol wan sat ai jak ni lawm ai.
Mawdaw Chassis hte wan n-gun matut mahkai ai lam
- Trailer chassis, madi shadaw ai lagaw ni, ga npu, makawp maga ai shingnip, etc ni lawm ai.
- Standard AC interface, lawan ai matut mahkai lam ni hte hpawng de da ai.
Hkamja lam chyam dinglik ai arung arai ni
Grai n-gun dat ai/Grau ai n-gun/Grau ai n-gun hpe makawp maga ai chyam dinglik ai lam
Shinggan na Short Circuit hte N-gun n-gun hpe shut ai hku jai lang ai chyam dinglik ai lam
Drop, Vibration, hte hkra machyi ai hpe chyam yu ai
Hkrun lam hprawng hkawm ai chyam dinglik ai lam
Madung bungli hte atsam marai ni
Jahtum/Hkyak hkyak wan n-gun jaw ai lam
N myit mada ai sha wan n-gun yawm mat ai, htingnut ai shara, nta gawgap ai shara, lamang galaw ai shara ni zawn re ai masa ni hta lang na matu htuk manu ai.
Grid Peak shading ai hte n-gun atsam hpe shayawm ya ai
Peak shaving hte valley hpe jahpring ai, ra kadawn ai lam hpe htai ya ai, frequency hpe hkang ai zawn re ai rawt jat galu kaba wa ai grid magam bungli ni hta shang lawm lu ai.
Diesel wan jak ni hpe galai shai ai (sh) jat bang ai:
Hkringmang daju a tsan ai shara ni (sh) grup yin hpe grai ra sharawng ai shara ni hta, mobile energy storage gaw, htunghking wan sau- hpe madung tawn nna wan n-gun shapraw ai hta, grup yin hpe grau shim lum ai hte sut masa lam hta grau akyu rawng ai.
Dai gaw bai gram lajang mai ai n-gun atsam ni hte rau bungli galaw lu ai.
Solar/wind power system ni hte matut mahkai nna, shani aten hta n-gun hpe mahkawng da nna, shana aten hta n-gun hpe shapraw ya lu ai.
On-site DC lawan ai hku charge galaw ai hte wan jak mawdaw hpe madi shadaw ya ai
Mobile n-gun shinggyin jak nkau mi gaw DC fast charge output hpe madi shadaw ya ai majaw, wan jak mawdaw ni hte kaga jak ni a matu lawan ai n-gun bai jat ya lu ai.
Laksan jai lang ai mabyin masa ni
◤Hkyak hkyak karum shingtau lam ni:Tsinyam hkrum ai ni hpe garum shingtau ai lam, wan n-gun shayawm ai lam, tsi rung backup wan n-gun
◤Gawgap na shara ni:Grid n lu ai shara ni a matu aten kadun wan n-gun jaw na
◤Shinggan lamang/madun poi ni:Nhtoi hte nsen-sumla jak ni a matu aten kadun wan n-gun jaw ai
◤Grid hpe madi shadaw ai:Grid peak shading ai lam hte ra sharawng ai lam hpe htai ya ai
◤Hkrang nnan bai gram lajang mai ai n-gun hpe hpawng de ai lam:Photovoltaic/nbung wan jak ni a matu n-gun mahkawng da ai lam hpe kaja dik htum galaw ai
◤Sut masa/Hpaga lamLaksan jai lang ai lam ni: PV hte n-gun shinggyin ai ladat (PV+ESS) hpe hpawng de da ai bungli galaw ai lam
Akyu hte manu dan ai lam
Hkrang n bung ai lam tsaw ai:
Hkam la mai ai, npawt nhpang gawgap ai lam n ra ai
grup yin hpe makawp maga ai:
Zero dat dat ai lam, nsen n pru ai sha bungli galaw ai
Hkamja lam tsaw ai:
Rawt jat ai BMS, nbung hpe hkang ai lam, hte makawp maga ai hkrang shapraw ai lam
Hpaji rawng ai lam tsaw ai:
N-gun atsam jai lang ai atsam grai law ai (90% du hkra (sh) dai hta jan ai)
Asak hkrung lam manu n law ai:
Diesel wan jak ni hta grau nna sut masa lam hta akyu rawng ai
Deployment Scenario law law hpe madi shadaw ya ai:
-site kaw -hte - hpe ginsup u
Mobile n-gun hpe mahkawng da ai gaw mau hpa hparan ladat n re; shi a manu gaw, ra kadawn ai atsam hpe jaw ya ai hta tatut galaw lu ai atsam hta rai nga ai. 261kWh hte 160kW hpe kayau kaya galaw ai gaw, grai kaba ai hku tsun ai n re, shara kaw tengman ai-mungkan n-gun manghkang ni hpe hparan na matu ra ai lam hpe hkrak tup tsun dan ai. Mungkan hpe n galai shai ya lu ai raitim, langai hkrai a shara ni hta bungli galaw ai ladat hpe teng sha galai shai ya lu na re. Dai gaw ahkyak ai daram rai nga ai.
